The remote control system

Here you get an overview of the remote control system of your XciteRC Flybar 400E and its various features
and settings. Before the first flight, you should absolutely have read and understood all these functions and
EN
settings.
• Do make sure that the transmitter is turned off - POWER-LED off.
• Now open the battery compartment cover on the backside of the transmitter. Remove the srew and slide
the cover down (1). Insert six AA batteries into the battery compartment of the transmitter (2). Pay atten-
tion to the correct polarity!
• Close the battery compartment cover, then turn on transmitter – push ON / OFF switch.
• After a few seconds the POWER LED will go out.
may not started – crash hazard! Change transmitter batteries immediately.
• WARNING: check the POWER LED also during operation. If the POWER LED starts to blink, stop
operation, switch the model off and replace the transmitter batteries – crash hazard!
ATTENTION: The maximum range of the remote control system is about 50 meters, do not fly
•
farther away under any circumstances! If the XciteRC Flybar 400E gets out of range, the fail-safe function
is activated and turns off the motor.

Transmitter

Antenna
Power-LED
Throttle stick
yaw
Throttle trim
Yaw trim
16
Backside
Mode switch
Mode-LED
Control lever
(forward-back, roll)
Forward-back trim
Roll trim
ON/OFF switch
The remote control system
Battery-
compartment
cover
6x 1.5 V AA batteries
WARNING: if the POWER LED flashes, the model
