1. TELESCOPIC ANTENNA
2. CD DOOR
3. TUNING CONTROL
4. TAPE (PAUSE, STOP/EJECT, F.FWD,
RWD, PLAY, REC) Key
5. VOLUME CONTROL
6. CARRYING HANDLE
7. MP3 FOLDER BUTTON
8. REPEAT BUTTON
PROGRAM (PROG) BUTTON
9. PLAY/PAUSE
BUTTON
BT MODE BUTTON
10. USB MODE INDICATOR
11. POWER INDICATOR
12. LED DISPLAY
13. PLAY INDICATOR
Power sources:
This unit operates on 230V~ 50Hz or 6 x DC1.5V "C" (UM-2) batteries. Do not
attempt to operate the unit on any other power source. You could cause damage to
the unit and void your warranty. Please be sure the power outlet you plug this unit
into is working and receives constant (unswitched) power.
AC OPERATION
Plug the detachable AC cord into a standard AC outlet (230V~50Hz).
1.
When the AC power cord (included) is connected to the AC POWER JACK (#22)
on the back of the unit and the other end is plugged into a 230V AC~ 50Hz wall
outlet, the unit will disconnect the batteries automatically, and operate on AC
Power only.
2.
Slide the FUNCTION SELECTOR (#26) to "CD/AUX/BT/USB" position for
CD/AUX/BT/USB play, "FM" for FM radio, "AM" for AM radio and "POWER OFF"
for unit power off.
•
Before connecting to the power outlet, ensure that the outlet corresponds to the
information on the rating label at the bottom of the apparatus.
BATTERY OPERATION
1. Remove the BATTERY DOOR on the bottom of the unit.
2. Install 6 x DC1.5V "C" (UM - 2) batteries (not included) according
to the polarity diagram inside the battery compartment.
3. Close the BATTERY DOOR
14. REPEAT INDICATOR
15. PROGRAM INDICATOR
16. STOP
BUTTON
CD/USB FUNCTION BUTTON
17. SKIP -
BUTTON
18. SKIP +
BUTTON
19. RIGHT SPEAKER
20. TAPE DOOR
21. LEFT SPEAKER
22. AC POWER JACK
23. USB JACK
24. HEADPHONE JACK
25. AUX-IN JACK
26. FUNCTION SELECTOR
(POWER OFF/TAPE/AM/FM/CD/AUX/BT/USB)
