For Surface Mounting using side conduit entrance
1
1
Drill out (3) mounting holes as shown for # 10
hardware (not supplied)
• Taladre (3) los agujeros de montaje como se muestra
para # el hardware 10 (not supplied)
• Percez (3) les trous de montage comme montré pour #
le matériel 10 (not supplied)
• Bohren Sie (3) Entlüftungslöcher wie gezeigt für #
Hardware 10 heraus (not supplied)
• Fure (3) furos de montagem como mostrado para # a
ferragem 10 (not supplied)
• Estragga (3) fori di montaggio come indicato per #
fissaggi 10 (not supplied)
For Surface mount applications
3
Connect conduit fitting to knockout
• Conecte el conducto que cabe con el golpe de
gracia
• Reliez le conduit s'adaptant au coup de grâce
• Schließen Sie das Rohr an, das an Ausscheidungswett-
kampf passt
• Conecte a canalização que cabe ao KO
• Colleghi il condotto che si adatta all'espulsore
For Surface mount applications
2
2
3
Mount securely to ceiling or mounting
surface using the appropriate hardware
• Monte con seguridad a la superficie del techo o de
montaje usando el hardware apropiado
• Montez solidement au plafond ou à la surface de
montage utilisant le matériel approprié
• Bringen Sie sicher zur Decke oder zur Befestigungs-
fläche unter Verwendung der passenden Hardware an
• Monte firmemente à superfície do teto ou de monta-
gem usando a ferragem apropriada
• Monti saldamente alla superficie di montaggio o del
soffitto per mezzo dei fissaggi adatti
For Pendant or Wall mount bracket applications
4
Remove plug with ⅝" Allen hex tool ( provided)
• Quite el enchufe con la llave Allen del ⅝" (provoded)
• Enlevez la prise clé Allen avec de ⅝ »(provided)
• Entfernen Sie Stecker mit ⅝" Inbusschlüssel (provided)
• Remova o plugue com chave Allen do ⅝
de"(provided)
• Rimuova la spina con chiave di Allen del ⅝„(provided)
