I G L O O D O M E
An Air-Conditioned Solution for hot, humid climates
Installation and Operation Instructions for the following models:
IGDW75C1N
Outdoor air conditioned dome housing with wall and pole mount, clear
polycarbonate dome, with 240VAC input, heater/blower, 120 to 24VAC
transformer for fixed camera
IGDW75T1N
Tinted version
Before attempting to connect or operate this product,
please read these instructions completely.
www.videolarm.com
CERTIFIED
81-IN5434
05-06-2010
Werbung
Inhaltsverzeichnis
Verwandte Anleitungen für Moog Videolarm IGDW75C1N
Inhaltszusammenfassung für Moog Videolarm IGDW75C1N
- Seite 1 An Air-Conditioned Solution for hot, humid climates www.videolarm.com Installation and Operation Instructions for the following models: IGDW75C1N Outdoor air conditioned dome housing with wall and pole mount, clear polycarbonate dome, with 240VAC input, heater/blower, 120 to 24VAC transformer for fixed camera...
-
Seite 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE Do not block any of the ventilation openings. -
Seite 3: Limited Warranty
LIMITED WARRANTY FOR VIDEOLARM INC. PRODUCTS VIDEOLARM INC. warrants this Product to be free from defects in material or workmanship,as follows: PRODUCTCATEGORY PARTS LABOR All Enclosuresand Electronics Five (5) Years Five (5) Years Pan/Tilts Three (3) Years **6 months if used in autoscan Three (3) Years **6 months if used in autoscan /tour operation /tour operation... -
Seite 4: Electrical Specifications
Electrical Specifications Mechanical Options Igloo Dome 1. Air ow sensor available to be combined with camera output systems to monitor the e ectiveness of air lter. If improper air ow is detected, sensor will send alarm. If user by passes air ow sensor, air lter should Power 120VAC . - Seite 5 Content of Box COOLANT...
- Seite 6 1/2" LOWER MOUNTING BOLTS STEP 1: Thread one retainer extrusion at the end of steel band, Position lower mounting bolts, washers and nuts as POSITION LOWER MOUNTING BOLTS, WASHERS AND NUTS AS SHOWN ABOVE., THREAD THE NUTS allowing 1” (254mm) of band out. Beveled end of UNTIL FLUSH WITH BOLT ENDS shown above.
- Seite 7 Place assembly around pole at desired mounting location. Thread mounting hardware and additional retainer extrusion Insert bolt through retainer extrusions. Head of bolt needs to at opposite end of steel band. Refer to Block 1 and 2 for lock into end of retainer. instructions.
- Seite 8 Installation is complete when nut is tight / secure and all slack has been removed from steel band. • La instalación es completa cuando es apretado la tuerca / garantizar la seguridad de todos y la atonía se ha eliminado de la banda de acero.
- Seite 9 Attach with (4) anchor bolts, (4) lock washers, and (4) Place the mounting plate against the wall flat washers • Fijación con (4) los pernos de ancla, (4) arandelas de cerradura, y (4) arandelas planas • Coloque la pletina contra la pared •...
- Seite 10 3/8" UPPER MOUNTING BOLTS SLOTS ON MOUNTING PLATE STEP 2: STEP 1: REST THE IGLOODOME UPPER MOUNTING BOLTS MOUNT ADAPTER PLATE TO POLE BY STEEL STRAPS ON THE SLOTS OF THE ADAPTER PLATE. INSERT LOWER BOLTS, WASHERS AND NUTS AND TIGHTEN ALL FOUR BOLTS Rest the IglooDome upper mounting bolts on the slots of Mount adapter plate to pole by steel straps...
- Seite 11 STEP 3: COMPLETE ELECTRICAL CONNECTIONS Route power and video cables through the water tight feed (at the base of the unit) • Encamine los cables de la energía y del vídeo a través de la alimentación apretada del agua (en la base de la unidad) •...
- Seite 12 Remove right side louver panel Set louver aside • Fije la lumbrera a un lado • Quite el panel de la lumbrera del derecho • Placez l'auvent de côté • Enlevez le panneau d'auvent de côté droit • Stellen Sie Luftschlitz beiseite ein •...
- Seite 13 Remove cap and still reservoir with Propylene Glycol/ water mix. Use mix ratio specified or container (*) • Quite el casquillo y aún el depósito con la mezcla del glicol/del agua de propileno. Utilice el cociente de la mezcla especificado o el envase •...
- Seite 14 Power up the unit by activating the “Primer” button as shown to circulate coolant through system. Add coolant after system stabilizes-if required (should be between the “High” and “Low” marker. • Accione para arriba la unidad activando el botón de la “cartilla” como se muestra para circular el líquido refrigerador a través de sistema.
- Seite 15 Mount louver panel(s) • Los paneles de la lumbrera del montaje • Panneaux d'auvent de bâti • Einfassungsluftschlitzverkleidungen • Painéis da grelha da montagem • Pannelli della feritoia del supporto Axis 213 (3) #8x3/8” ½" 2539 Mounting Plate Captive Screw 1"...
- Seite 16 Axis 214 Mounting Hole 3026 Mounting (3) #8 x 3/8” Plate Captive 2" Screw Mounting Mounting Hole Hole Install the camera to the mounting plate using (3) 3mm x 12mm bolts and lock washers. Place (3) #8x3/8” screws on the spacers and line up the mounting slots. Slide plate in and secure. •...
- Seite 17 AXIS 231-232D Axis 231D/232D Mounting Hole Loosen Screw Mounting Mounting Hole Hole Loosen the screw to the right of the tab by Use the (3) keyhole slots indicated above. approximately (5) turns. • Utilice (3) las ranuras del ojo de la cerradura indicadas •...
- Seite 18 Connection Module Screw Power Board Remove the power board located inside the housing. Attach the connection module as shown. This is what the typical path of illumination will look like with the setting at 30 degrees. Attach this assembly to the housing using (1) 6-32x3/8” screw and star washer. •...
- Seite 19 Axis 233D Mounting Hole Power Board Mounting Hole Disconnect the orange, red, and black wires. Remove the Use the holes indicated above to mount power board in the housing by loosening screws on the the camera. terminal block and the (4) machine screws. •...
- Seite 20 Quick Release Plate Additional Spacers Keyhole Slots Camera Bracket Base Bracket Mount the Axis 233D camera bracket and quick release plate using the additional spacers from This is what the typical path of illumination will look like with the setting at 30 degrees. the hardware packet.
- Seite 21 Canon VB-C10R ½" 2539 Mounting Plate Captive Screw 1" 2" Mounting Mounting Hole Hole Mount the camera to the 2539 plate using the provided hardware. Place (3) 8 x 32 x 3/8 Phillips head screws on the top of the spacer as shown above. Slide plate in and secure. Monte la cámara fotográfica a la placa 2539 usando el hardware proporcionado.
- Seite 22 Canon VC-C4R/VC-C50IR (3) 8 x 32 x 3/8 1" 2539 Mounting Plate Mounting Hole Captive Screw 1" 2" Mounting Hole Mount the camera to the 2539 plate using the provided hardware. Place (3) 8 x 32 x 3/8 Phillips head screws on the top of the spacer as shown above. Slide plate in and secure. •...
- Seite 23 Elmo PTC-201 2539 Mounting Plate Mounting Hole Captive Screw ½" 2" Mounting Hole Place the camera onto the quick release bracket using the (4) metric 3M Phillips head screws provided. Place the screws on the spacers. Slide on the plate and camera then secure. •...
- Seite 24 Elmo PTC-401 2539 Mounting Plate Mounting Hole Quick release 1" plate Captive Screw 2" Mounting Hole Attach quick release bracket to mounting plate using (4) #8 screws and star washer. Complete assembly as shown, then secure camera to the quick release plate. •...
- Seite 25 JVC VN-C625U / TK-625U 1" Mounting 2630 Mounting 1" Hole Plate Remove the cover and detach bracket. Attach (4) 1” spacers to the 2630 mounting plate and (4) to the main bracket. Place (3) 8x32x3/8” Phillips screws onto the spacers. Secure plate and camera. •...
- Seite 27 Sony SNCRZ25 Mounting Hole 1" 2539 Mounting Plate Mounting Hole Attach bracket with (1) 1/4x20 bolt, washer and lock washer and (2) 3mm x 8mm Phillip head screws and lockwashers. Place the screws on the spacers. Slide on the plate and camera then secure. •...
- Seite 28 Sony SNCRZ50 Mounting Hole ½" 2" 2539 Mounting Mounting Hole Plate Attach bracket with 3mm x 8mm bolts and lock washers. Place (3) 8x32x3/8”screws on the spacers. Slide on the plate and camera then secure. • Una el soporte con los pernos de 3m m x de 8m m y las arandelas de cerradura. Coloque (3) 8x32x3/8"screws en los espaciadores.
-
Seite 29: Replacement Parts List
Replacement Parts List Igloo Dome 1 RPFD7501 TRIM RING FD75 2 RPGK3524 TRIM RING INSULATION FD7T TINTED REPLACEMENT CAPSULE FD7C CLEAR REPLACEMENT CAPSULE 4 RPFD703 DOME CLAMPING BRACKET 5 RPVL3414 CAMERA BRACKET 6 RPGK3521 HOUSING INSULATION 7 RPVL2593 HOUSING 8 RPVL3164 BOARD SHELF 9 RPGK3209 TOP INSULATION... - Seite 30 Replacement Parts List Igloo Dome 31 RPVIMU3ES POWER SUPPLY 32 RPBLEH12 BLOWER 60 X 60 X 25 33 RPPLTCONT PELTIER DEVICE CONTROL BOARD 34 RPVL2004 CONTROL BOARD 35 RPZPSA6012 POWER SUPPLY 36 RPVLBL08 120X38mm FAN 37 RPGK3415 RADIATOR SEALING 38 RPIGRDTR RADIATOR 39 RPVL3210 POLE MOUNT BRACKET...
-
Seite 31: Product Information
Product Registration/Warranty Thank you for choosing Videolarm. We value your patronage and are solely committed to providing you with only the highest quality products available with unmatched customer service levels that are second- to-none in the security industry. Should a problem arise, rest assure that Videolarm stands behind its products by offering some of the most impressive warranty plans available: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on all camera systems (SView, QView, Warriors), and InfraRed Illuminators.
