SURGES
Specifications
Inputs
Audio Input 1
Audio Input 2
Frequency CV
Resonance CV
Volt/octave
LPF output level
Outputs
High Pass Filter
Band Pass Filter
Low Pass Filter
Controls
Controls
Switches
3.5 mm TS jack,
impedance 100 kΩ
3.5 mm TS jack,
impedance 100 kΩ
3.5 mm TS jack,
range -8 V to +8 V
3.5 mm TS jack,
range -8 V to +8 V
3.5 mm TS jack,
range -3 V to +7 V
3.5 mm TS jack
range 0 V to +7 V
3.5 mm TS jack,
impedance 1 kΩ
3.5 mm TS jack,
impedance 1 kΩ
3.5 mm TS jack,
impedance 1 kΩ
Frequency
Resonance
Frequency CV
Attenuverter
Input 1 Gain
Filter Slope
Quick Start Guide
Power Requirements
Power supply
Current draw
Physical
Operating
Temperature
Dimensions
(H x W x D)
Rack units
Weight
81
Eurorack
35 mA on both
+12 V and
-12 V rails
5° C - 45° C
(41° F - 113° F)
129 x 40 x 41 mm
(5.06 x 1.59 x 1.62")
8 HP
0.19 lb
