S EC R ET L AB L AP TOP MO UNT AT TACH MENT
AS S EM B LY G U ID E
Before you proceed, ensure that your
monitor arm is fully extended.
To install your Laptop Attachment to the
arm, slide the VESA Bracket into the
VESA mount on the upper arm. When
fully attached, you should hear it click
into a locked position.
To release the laptop attachment, push
the quick release pedal away from the
attachment and slide it out.
OTHER LANGUAGES
To view this manual in the following languages, please scan the QR Code to the left.
Pour consulter ce manuel dans les langues suivantes, veuillez scanner le QR code à
gauche.
Um dieses Handbuch in den folgenden Sprachen anzuzeigen, scannen Sie bitte den
QR-Code auf der linken Seite.
Scan de QR-code naar links om deze handleiding in de volgende talen te bekijken.
本マニュアルを以下の言語でご覧になるには、 左の QR コードをスキャンして ください。
해당 설명서를 다른 언어로 보시려면, 왼쪽에 있는 QR 코드를 스캔하세요
เพ� ่ อ ดู ค ู ‹ ม ื อ นี ้ ใ นภาษาต‹ า ง ๆ โปรดสแกน QR Code ที ่ อ ยู ‹ ด Œ า นซŒ า ย
Đ xem s tay hư ng d n này b ng ngôn ng khác, vui lòng quét Mã QR bên trái.
Untuk melihat panduan ini dalam bahasa lainnya, silakan scan QR code di sebelah kiri.
NEED ANY HELP?
For additional support and full warranty terms and conditions, please scan the QR code
or visit our website
secretlab.co/support
<
>
ARM ADJ USTM ENT S
01
A. Tilt Adjustment (M5) and B. Laptop Swivel (M3)
Adjust the screws on for the desired ease of laptop swivel and tilt resistance.
Tilt your laptop attachment at an angle and place your laptop on it. Continue
adjusting the swivel and tilt resistance to your desired amount if necessary.
NOTE: We recommend that you carry out these adjustments without your laptop mounted.
02
Laptop Weight Adjustment (M5)
If the arm rises up on it's own, rotate the Adjustment Screw
counterclockwise (towards -) to lower the arm's lift force. If the arm
falls down with the weight of the laptop, the lift force is too low and can
be increased by turning the Adjustment Screw clockwise (towards +).
For your laptop's safety, avoid tilting the laptop attachment to a vertical 90° angle.
It is advised to limit the tilt angle to a maximum of 75°.
