1. General instructions
Read and observe the operating instructions, keep them as a reference for
later and ensure they are accessible at all times.
Warning symbols
WARNING
CAUTION
i
QR code for further product information
https://hog.tools/081567-205
2. Safety
2.1. GROUPED SAFETY MESSAGES
2.1.1. Battery
CAUTION
Leaking electrolyte
Eyes and skin irritation can occur due to leaking, poisonous and corrosive electro-
lytes.
▶ Avoid contact with your eyes and body.
▶ In the event of contact, rinse out the affected area immediately with plenty of
water and consult a doctor.
2.2. INTENDEND USE
For both industrial and private use. Protected against dust and sprayed water to
IP 65.
2.3. REASONABLY FORESEEABLE MISUSE
Do not use in potentially explosive atmospheres. Do not open the casing. Do not ex-
pose to strong heat, direct sunlight or open fire. Do not replace the light bulb. Not
suitable for use by children. If the casing is damaged, do not continue to use the
work lamp.
3. Device overview
A
1 LED light 2 spotlight 3 USB-C charging connector charging 4 /discharging LED
on/ 5 off push button 6 suspension hook 7 holding magnet
4. Supplied with
1x LED battery work light, 1x USB-C charging cable
5. Commissioning
5.1. CHARGING THE BATTERY
i
Fully charge the rechargeable battery before using it for the first time.
ü Torch switched off.
1. Connect the light to the power socket using the USB-C charging cable and the
power supply.
▶ LED lights up red during charging.
2. Disconnect the light from the mains.
6. Operation
WARNING
Risk of blinding and injury to the retina
▶ Never look directly into the light beam.
▶ Do not direct light beam at animals' or people's eyes.
▶ In the event of commercial use, the user must be instructed according to the ac-
cident prevention regulations.
6.1. SWITCHING LIGHTS ON/OFF
1. Press the on/off button again to switch on the main light in "Eco mode".
2. Press the on/off button again to switch on the main light in "Full Power Mode".
3. Press the on/off button again to switch on the spotlight.
4. Press the on/off button again to switch off the lamp.
6.2. ATTACHING THE LIGHT
The magnet adheres to all smooth, flat, magnetic surfaces.
7. Storage
Before placing the lamp in storage, fully charge the battery. Store at temperatures
between -10°C and +40°C. Do not store in the vicinity of acidic, aggressive, chemical
substances, solvents, humidity and dirt.
8. Cleaning
Disconnect from the power supply before starting cleaning. Clean with a slightly
damp cloth. Do not use chemical, alcohol-based, abrasive or solvent-based cleaners.
Meaning
Indicates a hazard which if not avoided
may lead to death or serious injury.
Indicates a hazard which if not avoided
may lead to minor or moderate injury.
Indicates useful tips and instructions to-
gether with information for efficient and
problem-free operation.
9. Technical data
Length
Weight (with battery)
Luminous flux LED light
LED light duration
Illumination of spotlight
Illumination time of spotlight
LED
Protection class
Ambient temperature range
Rechargeable battery
Charging duration
Charging voltage DC/current
10. Recycling and disposal
Torch and rechargeable battery must not be disposed of in domestic waste.
Comply with the national regulations for disposal. Torch and rechargeable
battery must be taken to a suitable collection point.
205 mm
205 g
Brightness level 1 – approx. 150 lm
Brightness level 2 – approx. 350 lm
Brightness level 1 – approx. 6.5 h
Brightness level 2 – approx. 3.0 h.
Approx. 125 lm
approx. 9.0 hours
COB LED
IP 65
-10°C to +40°C
Li-Ion 3.6 V, 2600 mAh
Approx. 4 h
5 V, 1 A
