Bullard Firedome FXE Gebrauchsanweisung

TM
Instructions for Providing a
Comfortable and Secure Fit
To size the Sure-Lock® ratchet headband:
1. Turn the ratchet knob counterclockwise until headband is
at largest size (Figure 1).
2. Place the helmet on your head and turn the ratchet knob
clockwise until headband is snug and comfortable.
To adjust helmet vertically:
1. Locate the vertical adjustment tabs at the front and back
of the headband. There are four tabs on the headband
and four black posts on the inner liner.
2. To raise or lower the headband, reposition the tabs on
the black posts and snap in place (Figure 2).
To raise or lower Faceshield:
1. Release tension knobs found on both sides of the
helmet.
2. Tighten knobs once faceshield is in desired position.
Firedome ® FXE, PXE, RXE Helmet
Use
This product is only intended for use as described in this
manual.
Maintenance
Only original parts by the manufacturer may be used for
maintenance.
Cleaning and disinfecting
Remove ear/neck protector, headband, and crown
straps. Clean inner and outer shells with mild soap or
detergent. Wash the ear/neck protector, headband,
brow pad, and crown straps in warm, soapy water and
air dry at room temperature. Clean faceshields with mild
detergent, rinse thoroughly with clean water, and dry
with a soft cloth.
Figure 1
Do not use solvents or paint thinners on Firedome
helmets, as they could permanently mar surfaces or
degrade the protective properties of helmet
components. Touch-up painting on composite outer
shells can be done with Bullard-approved paints.
Failure to follow these instructions could reduce the
effectiveness of the helmet and result in death or
serious injury.
Storage
Wipe helmet and shield with anti-static cloth and store
in a cool, dry place where the helmet will be protected.
Transportation/Shipment
Helmet should be packaged in its original package to
ensure that it is protected from damage during transit.
Read all instructions and warnings before wearing
this helmet. Failure to follow these instructions could
Figure 2
cause death or serious injury.
User Manual
WARNING
WARNING
