Safeline EVAC Bedienungsanleitung

EVAC manual
LIFT EVACUATION
INTERCOM
TALK
Fire Communication
www.safeline-group.com
11.2023
SafeLine EVAC v.2.4.0 INT
Complies to EN81–28 and EN81–70 standards.
PATENT 08163634.2
© 2023 SafeLine and all the SafeLine products and
accessories are copyrighted by law.
Fig. 1.1
EVAC entrance station
Fig. 2.1
EVAC floor station
2 x Ø 4
0 1
1
2
400 mm
366 mm
3
4
5
6
TALK
7
110 mm 29 mm
2,5 mm
2 x Ø 6
LIFT EVACUATION
INTERCOM
1
210 mm
176 mm
2
3
17 mm
22,5 mm
90 mm 25,2 mm
