CARBEST | Gas Cooker | 70576 / 70577 / 70578/ 70579/ 70580
The appliance must be fastened to the unit using silicone or equivalent.
If you wish to install the appliance flush with the unit, it is necessary to mill (1 cm wide, 1 cm deep)
the hole cut into the unit.
To fasten the appliance, apply a strip of silicone along the underside edge of the glass Insert the appli-
ance into the hole in the unit, pressing it down gently until the silicone hardens (at least 3 hours).
The appliance is now fastened to the unit. For any maintenance operations requiring the dismantling of
the appliance from the unit, cut the silicone using a cutter. Before re-fastening the appliance, clean any
silicone from the glass of the appliance and the hole in the unit.
5. GAS CONNECTION
Before connecting the gas supply, make sure that the local distribution conditions (type and pressure
of gas) and the adjustment of the appliance are compatible. The appliance adjustment conditions are
indicated on the data plate on the underside.
The appliance input consists of a gas ramp with the end facing sideways, to simplify installation.
The end is cylindrical, 8 mm diameter, unthreaded, for at least 30 mm. Where permitted by the instal-
lation standards in force, connection to the gas main may take place using a flexi-pipe with a gas-proof
press fitting (complete with ogive).
In the specific case of built-in installation, UNI 7131 forbids direct connection of the appliance to the
gas bottle by flexi-pipe. It is therefore necessary to connect the appliance to a fixed system (UNI 7129),
which will be connected to the gas bottle and the appliance by flexi-pipes (UNI 7140) with a rubber
insert support and relative clamps (UNI 7141). The flexi-pipe must have a maximum length of 1.5 m,
without intermediate joints, and must not run through two different rooms. The connections must not
cause the pipe to twist, bend or be crushed and the pipe must not come into contact with sharp items
or edges and must not exceed a temperature of 50°C. The flexi-pipe and relative rubber insert support
must be open to inspection.
The regulator fitted to the gas bottle must be compliant with EN 12864.
To make the flexi-pipe of the appliance suitable for connection, use a rubber insert support compliant
with UNI 7141, with relative clamps, at the appliance end. It is necessary to use an adapter for this (if
not supplied with the appliance, ask Technical Assistance for one). This adapter will be connected to the
smooth end of the appliance by a gas-proof press fitting and connected to the rubber insert support by
a threaded connection (compliant with ISO 7-1 if the rubber insert holder is not supplied with the appli-
ance). Pay attention to the marking of the threading on the adapter: check that it is compatible with that
of the rubber insert support.
CAUTION: Upon completion of installation, check the seal of the connection in compliance
with the methods indicated by the legislation in force. Never use a naked flame.
Checking the correct operation of the burners
When the appliance is installed, check that all the burners work properly.
Check the ignition, in compliance with the Instructions for Use section, the stability of the flame, the
maintenance of the flame when turning the knob from maximum to minimum. The flame must not flare
up or go out.
25
