PM63 Operating Instructions Digital Contact Pressure Gauge

TECHNICAL DATA

Measuring range
Pressure range
Output
Analog output
Contact output
Power supply
20 mA output
10 V output
Signal characteristics
Accuracy
Long term stability
Response time
Swich-on time
Temperature coefficient
Zero
Span
Temperature ranges
Medium temperature
Surrounding temperature
Storage temperature
Electrical protections
Short-circuit resistance
Reverse polarity protection
Electromagnetic compatibility
Wetted materials
Process connection
Sensor
Sensor seal
Surroundings
Protection type
Exemplary weight
PM63-A11-DD-11 (figure p. 1)
Nöding Messtechnik GmbH • Oldenfelder Bogen 29 • D-22143 Hamburg, Germany • Tel.: +49 40 67 58 51 – 0
Fax: +49 40 67 58 51 – 49 • Internet: www.noeding-messtechnik.de • E-mail: info@noeding-messtechnik.de
See table „ Measuring ranges"
others on request
0 (4)...20 mA 2-wires
0...10 V 3-wires
1x DC PNP, max. 200 mA
10...30 V DC
16...30 V DC
≤ ± 0,5 % FS @ 25 °C
≤ ± 0,5 % FS / Y ear
200 ms - others on request
< 1 s
≤ ± 0,03 % FS / Kelvin
≤ ± 0,02 % FS / Kelvin
-25...100 °C
-25...80 °C
-40...85 °C
Permanent
Protection against reverse polarity, but no function
Interference emissions and immunity acc. to EN 61326
Stainless steel, 1.4404
Ceramic Al O
2 3
FPM (Viton), NBR, EPDM, FFKM (Chemraz / Kalrez)
IP 67
ca. 300 g

ELECTRICAL CONNECTION

Connector M8x1 4-pole
brown
white
black
blue
SP1
LOAD
R / Ω
B
1000
10V
EN
u
B
30V
