Doss Extreme Boom Schnellstartanleitung Seite 2

EN
1. Packing content
1 x Extreme Boom
●
1 x USB-C charging cable
●
1 x Strap
●
1 x Quick start guide
●
2. Specifications
Bluetooth range: up to 20m/66ft
Output power: 60W
DC power input: 5V
USB output: 5V
Capacity : 9000mAh
Charge time: 5hrs
Playtime: 25hrs (at 50% volume-Hotel California)
Net weight: 2.08Kg (4.6lbs)
Dimension: 323*120*184 mm (12.7*4.8*7.3inches)
TF card audio format: MP3/ WMA/ FLAC (Max capacity 256G)
3. Important notes before using
To prolong the lifetime of the battery, fully charge it before first time using.
●
The battery is at low level when the leftmost LED blinks.
●
The speaker will auto power off after 15 minutes without audio input.
●
To cancel the auto power off feature, press and hold
●
The USB out is only for charging your device.
●
Restore factory setting by press and hold the
●
Press any button to check the battery level while not charging.
●
When all buttons can't be controlled, try to poke the Aux port with a paper clip.
●
If you need any assistance while using this speaker, please feel free to contact
●
customer service at support@dossav.com.
4. Buttons and control
Buttons Function
Turn on/ off
Extra bass on/ off
Volume down
Previous track
Play/ pause
Reconnected to the last device
Disconnect device(s)
Volume up
Next track
Switch audio input modes
Enter/exit TWS mode
5. LED indication
Solid white
Off
Flashing blue
Solid blue
Solid red
Solid green
Rapidly flashing green
Solid white
6. Connections
1
2
3
AUX in (not supplied)
4
2A
2A
1 2
Max ouput 5V
TF card (not supplied)
for 2s simultaneously.
How to control
Press and hold
Press
Press
Press and hold
Press
Press
Press and hold
Press
Press and hold
Press
Press and hold
battery level 25%
battery level 50%
battery level 75%
battery level 100%
Extra bass on
Extra bass off
Bluetooth pairing
Bluetooth paired
Aux in mode
TF card mode
Max volume
TWS mode
3 4
2A
for 2s simultaneously.
5V 2A
