BASIC INSTRUCTIONS FOR USE
Attaching the belt attachment:
With ClicLoc System:
To loosen the carrying strap and unlatch the lock, press and hold the marked oval position on the rubber armouring .
1
The snap fit can now be pulled off and/or inserted. Make sure that the catch is always facing outwards and that it
audibly engages while being inserted.
Without ClicLoc system:
Please loosen one end of the strap from the side loop and feed the strap from the top through the eyelet . Now
2
pull the carrying strap through the slide loop again and pull firmly on the strap to tighten it. Repeat these steps to
fasten the other end of the strap in the same way. For carabiner closure follow the picture sequence .
3
Attaching the neoprene protection cover and the rain protection cover:
Several rain protection systems may be enclosed with your binoculars that are attached to the carrying strap. For
neoprene protection covers, please ensure that the semicircular opening on the cover is placed over the focussing
. For rain protection covers, the strap retainer may be threaded laterally through the open eyelet
wheel
4 5
provided for this purpose .
Attaching the objective protection covers:
If your binoculars are equipped with locking ClicLoc objective protection covers, press on the visible depression to
release the cover and pull it out of its retainer . To re-connect it, push the snap-on fastener back into the retainer
6
until it is secure and audibly engages. Objective protection covers that are attached to the centre axis are removed
by pulling them over the centre axis .
7
