GOAL ZERO YETI TANK Installationsanleitung Seite 6

Getting Started
In the Box
1. 1x MP120 to Ring Terminal Long 3' with 80 A Fuse (SKU 98108)
2. 1x MP120 to Ring Terminal Short 2' (SKU 98109)
3. Tank Rework SOP
1
MP120 To Ring Terminal Long 3' with 80 A Fuse
(To Yeti Link)
Additional Items Needed for Installation (Not Included)
1. 5/32 inch Allen wrench
2. #2 Phillips screwdriver
3. 13 mm socket or wrench
4. 9/16 inch socket or wrench
10
2
MP120 To Ring Terminal Short 2'
(To Expansion Tank)
Tank Disassembly
1. Remove the 4 corner Allen head screws.
2. Remove the 2 center Phillips head screws.
3. Lift the lid and remove the positive terminal 13mm bolt and washer. Then remove the negative terminal 13mm bolt
and washer (Fig. 2). Set bolts and washers aside -- will need for reassembly.
Fig. 2
11
