TOOLS REQUIRED
SCREWDRIVER M10 WRENCH
(BRING YOUR OWN） (PROVIDED)
HARDWARE
1 2
φ12 GASKET
M4*12mm
SCREW
x9 x6
5 6
SPRING M10 IRON
（OPTIONAL）
WRENCH
x2 x1
PARTS
A B
FRONT WHEEL REAR WHEEL
x2 x2
F
E
STEERING
FRONT BAR
WHEEL
x1 x1
08
APPROXIMATELY
2 PERSON 45 MIN
ASSEMBLY ASSEMBLY
3 4
φ10 WASHER
M10 NUT
x6 x2
C D
WHEEL COVER FRONT BUMPER
x4 x1
G
H
REAR BAR TAIL
x1 x1
I J
SEAT REMOTE
CONTROL
x2 x1
M N
DUAL DRIVE
GEAR BOX (L/R)
FRONT BRACKET
(OPTIONAL)
x2 x1
Q R
TAIL LAMP
FRONT BUMPER
DECORATION
BASE
(L/R)
x1 x1
K L
CHARGER REAR AXLE
x1 x1
O
P
NET BAG
SPRING SLEEVE
(OPTIONAL)
x1 x2
