Then, lay the plate into the channel until it is squarely
aligned. Finally, turn the quick-release plate lock knob until
the plate with the attached optic is secure in position.
CAUTION:
DO NOT LET GO OF THE MOUNTED OPTIC UNTIL YOU ARE CONFIDENT
THAT THE MOUNTING PLATE IS FIRMLY SECURED TO
THE TRIPOD HEAD.
ADJUSTING THE CENTER COLUMN
The center column of the Hummingbird tripod can
be extended to raise the tripod head when additional
height is needed. To extend the center column, twist
the center column lock knob and move the center
column to the desired height. Once the head is in
place, tighten the center column lock knob to secure.
Quick-release plate
Quick-release
plate lock knob
Center column
lock knob
Center column
