RIKO TEAM Gebrauchsanweisung Seite 11

OPERATION MANUAL
UNFOLDING THE STROLLER
1), and pull the stroller guiderail upward until fully unfolded
ATTACHING AND DETACHING REAR WHEELS
rear suspension. Slide the pointed end of the half axle into
click in place. Then slide the wheel onto the half axle and
NOTE! Before starting to use the pram, make sure that all the
wheels have been assembled correctly.
To disassemble the rear wheels, press down the button in the
central part of the wheel (Fig. 6) and remove the wheels from
the axle (Fig. 7). To detach the rear half axle push the button
ASSEMBLING AND DISASSEMBLING THE FRONT
SWIVELLING WHEELS
In order to assemble the front wheels, force their axles in the
ends of the front legs, until you hear a characteristic "click"
(Fig. 9). In order to disassemble the wheels press down the
button at the upper part of the swivelling mechanism (Fig. 10)
and slide the wheel axle in.
The stroller has swivel wheels, which may be locked in a
forward facing position. In order for the wheels to swivel,
twist the knob in the upper part of the wheel mount in an
anti-clockwise direction. To lock the wheels turn the knob in a
HANDLE HEIGHT ADJUSTMENT
It is possible to adjust the pram handle height. To perform the
adjustment, press down the round buttons on both sides of
the handle at the upper part, and then adjust the right height
(Fig. 12).
PARKING BRAKE
The pram is equipped with a rear parking brake. To engage
the brake, press its lever down (Fig. 13). In order to
disengage it, lift the lever.
NOTE! Before starting to push the pram, make sure that the
brake has been disengaged.
NOTE! Always engage the safety brake, when you leave the
pram on an inclined surface.
NOTE! The brake is not designed for slowing down. It should
be engaged after the pram has been stopped completely.
NOTE! The pram is not designed for running.
ADJUSTING SUSPENSION STIFFNESS
ATTACHING AND REMOVING THE CARRYCOT
In order to attach the carrycot press it into the pram frame so
that the adapters on both sides of the carrycot lock onto the
automatically.
ATTENTION! Make sure the carrycot is attached correctly
prior to use.
To remove the carrycot press the buttons on the adapters
upwards.
ASSEMBLING AND DISASSEMBLING THE SEAT
The seat should be assembled and disassembled the same
way as for the carrycot (see ATTACHING AND REMOVING
The seat may be assembled with its front and back facing the
movement direction.
NOTE! Before starting to use the pram make sure that the
seat has been assembled correctly.
RESTRAINT SYSTEM
19). It should be used from the moment a baby starts to sit
by itself. Unfasten the belts, by releasing the forks from the
central buckle, seat the baby, adjust the length of the belts so
and then fasten the forks of all the belts to the central buckle.
The seat has an additional crotch strap which should be
additional element and not be a substitute for using the 5
point safety harness.
NOTE! Always use the restraint system, if the baby can sit
by itself.
SAFETY BAR
To attach the bar, insert its tongues into the slots in armrests.
To remove it, push the buttons located on the bottom of the
The bar is adjustable. You can detach one of its ends and
22).
NOTE: The bar is an extra element and you must still use the
ADJUSTING THE LEG REST
The pram is equipped with an adjustable leg rest. To move it
to the right position, press down the buttons on its both sides.
BACKREST ADJUSTMENT
The seat has an adjustable tilt angle. To make adjustments,
press the buttons on both sides of the seat and tilt them to
RAIN FOIL
The pram is provided with a rain foil equipped with an air hole
at the baby's face height. To assemble it, put one end under
the leg rest or under the carrycot rear, and pull the other end
onto the canopy
version.
FOLDING THE STROLLER
Before folding the stroller, remove the child seat or the
carrycot.
To fold the stroller frame, push the button on the upper part of
until total folding
11
