7. Extraction Connector
8. Fence
9. Fence Knob
10. Table Scale
11. Module Levelling Screw
12. Thumb Hole
13. Featherboard Adjuster Knob
14. Fence Face
15. Module Mounting Rollers & Tracks
16. Cutter Height Winder Slot
17. Guard
18. Direction Indicator
19. Horizontal Featherboard
20. Featherboard T-Slot Knob
21. Featherboard Adjuster Knob
22. Module Levelling Bobbin Screw
23. Fence Face Adjustment Knob
24. Micro-Adjuster
25. Fence Slot
26. Fence Micro-Adjuster Knob
27. Table Scale Indicator
Intended Use
An effective router table capable of edge rebating, trenching, cross
trenching, planing, edge moulding (fence and free hand), end
grain work, using a template guide, and morticing. For use with the
Triton Workcentre TWX7 and Triton Routers.
Unpacking Your Tool
• Carefully unpack and inspect your new tool. Fully familiarise
yourself with all its features and functions.
• Ensure that all parts of the tool are present and in good
condition. If any parts are missing or damaged, have such parts
replaced before attempting to use this tool.
IMPORTANT: Read these instructions in combination with the
instructions supplied with your Triton router and the Triton
Workcentre.
For instruction video, please go to www.tritontools.com
Before Use
WARNING: Ensure the router is switched off and disconnected
from the power supply before attaching or changing any
accessories, inserting or removing modules or making any
adjustments.
Installing & removing the router module
See 'Installing and removing modules' in the main Workcentre
EN
TWX7 manual for a complete guide.
WARNING: Lower the router cutter to a safe height position
before installing or removing the router table module.
WARNING: Some modules are heavy, especially with power
tools installed. ALWAYS grip modules with both hands, ensure
secure footing, stand upright, and avoid awkward movements
when removing and fitting modules.
6
IMPORTANT: Always lower modules carefully using both
the provided Thumb Holes. Uncontrolled lowering can cause
Workcentre, module and power tool damage as well as possible
injury to the operator.
WARNING: Do not place fingers and/or body parts between the
module and the Workcentre chassis. See Fig. L
To remove: Toggle the Module Locks to the unlocked position (see
Fig. M). Using both Thumb Holes (12) to tilt the module to 45° then
slide and lift out.
To insert: Locate the Module Mounting Rollers in the Module
Mounting Tracks (15) as a hinging point and lower the module
down. Use the Thumb Holes to lower to a level position and then
re-lock the Module Locks.
Note: Modules can be stood upright by angling them to around
120°. This position can be used when adjustments on the
underside of modules are necessary, e.g. adjustments to the fitted
power tools, and there is no need to remove the module.
Assembling the router table module
• Use the Figures provided; A-K to assemble the router table
module. Step B requires additional information below.
Note: P1-6 on Fig. A is the Starting Pin for freehand operation and
only requires fitting for freehand operation.
Fitting a Triton router to the router mounting plate
• The mounting plate is on the underside of the table and has
been designed for direct mounting to any of the compatible
Triton Routers (JOF001, MOF001, TRA001, TRA002 and
TFBR001).
WARNING: Remove the plunge spring on the JOF001, TRA001
and TRA002 to configure the router for table-mounted operation.
See the original router manual for procedure. Store the spring
carefully as it will need to be re-fitted when the router is removed
from the router table module.
WARNING: The plunge spring on the JOF001 plunge router
must not be removed before installing on the router table.
1. Remove the plastic cover of the base plate of the router by
removing the securing screws. The screws and plastic base
plate should be safely stored for when they may need to be
re-fitted in the future.
2. Ensure the base of the router is completely clean so it will be
level with the mounting plate when fitted.
3. Loosen the two mounting knobs on the router until the bolt
heads can protrude approximately 10mm (3⁄ 8 ") above the base
of the router.
4. Push down on the mounting knobs until the bolt heads locate
into the keyholes, then rotate the router anticlockwise until the
knobs align with the small triangle holes (Fig. B).
5. Tighten the mounting knobs firmly.
6. Ensuring all mains power is switched OFF, connect the power
cable plug of the power tool to the mains socket of the
Workcentre not directly to a wall socket or other mains outlet.
Note: Early Triton TRA001 routers do not feature a table winder
connector.
Levelling the throat plate
1. Level the throat plate in the router table using a square and the
supplied hex key to adjust the levelling screws (see Fig. N).
