AIDOO PRO AS A COMMUNICATION GATEWAY
Devices included in the solution:
•
AZAI6WSPxxx - Aidoo Pro for Direct Expansion
•
One of the following devices:
a.
AZCE8CB1MOT - Airzone Flexa 4.0 main control board
b.
AZPV8CBxIAQ - Easyzone IAQ main control board
c.
AZCE6FLEXA3 - Airzone Flexa 3.0 main control board
d.
AZPV6CB1MOT - Easyzone main control board
e.
AZCE6IBPRO6 - Airzone Innobus Pro6 main control board
f.
AZDI6ACUAZONE - Airzone Acuazone main control board
g.
AZxxxCBx[aaa] - Airzone VAF system central
Connection
Connect the RS485 port of the Aidoo Pro to the system's main control board IU port, i.e., where
the communication gateway would normally be connected.
