WINDING PROGRAM PARAMETERS
The module winder has 5 TPD settings and 3 directional modes, giving 15 possible
rotation programmes (clockwise/counterclockwise/clockwise + counterclockwise).
There are 5 different rotation programmes with respect to the TPD settings and
their parameters are listed in the following table. The actual number of revolutions
is double the TPD value when the rotator is in bi-directional mode.
TPD
650
750
850
1000
1950
650 TPD
10 turns every 665 seconds, rotate for 12 hours and rest for 12
hours then repeat.
750 TPD
10 turns every 576 seconds, rotate for 12 hours and rest for 12
hours then repeat.
850 TPD
10 turns every 508 seconds, rotate for 12 hours and rest for 12
hours then repeat.
1000 TPD
10 turns every 432 seconds, rotate for 12 hours and rest for 12
hours then repeat.
1950 TPD
10 turns every 222 seconds, rotate for 12 hours and rest for 12
hours then repeat.
Note
•
Do not remove or insert a watch during operation.
•
Do not move the turntables by hand at any time.
•
If you don't use the watch winder for a long time, please make sure that the
mains plug is unplugged.
•
Operating temperature is within 0 °C and 40 °C
Number of cycles
70
72
72
72
72
Turns per cycle
539
504
436
360
150
Cycle period (seconds)
665
756
508
432
222
EN
15
