EN
The compressor (1) is hot or is making
unusual noises.
The compressor is overloaded.
► Switch it off immediately and allow it
to cool down for at least 30 minutes.
The battery pack (5) is not charging up.
The control lamp of the mains adap-
ter (4) does not light up.
Spare parts for
safety critical use
1
Motor
2
Switch
3
Circuit board
4
Pressure sen-
sing trachea
assembly
5
PCB assembly
6
DC Motor
7
Motor gear
8
Big Plastic gear 8
9
Rocker
10 Piston
11 Cylinder
12 Fan
13 Battery pack
14 Air Tube
22
07703_Inlay_de-en-fr-nl_A5_V3.indb 22
07703_Inlay_de-en-fr-nl_A5_V3.indb 22
The mains adapter is not inserted correctly
in the plug socket or the barrel connector
is not inserted correctly in the charging
socket (14) of the battery pack.
The plug socket is defective.
Parts and consu-
mables that need
periodic inspection or
replacement
1
Motor
2
Switch
3
PCB assembly
4
Pressure sen-
sing trachea
assembly
5
Big Plastic gear
6
Rocker
7
Battery pack
Air Tube
9
Fan
10
Adapter (e.g for
air mattresses,
inflatable toys)
11
Adapter (e.g
balls, sports
equipment)
► Correct the connections.
► Try another plug socket.
Schedule for periodic inspection and
replacement of parts and consuma-
bles
1
Air Tube
2
Adapter / Plas-
tic noozle (e.g
for air mattres-
ses, inflatable
toys)
3
Adap-
ter / Needle
noozle (e.g
balls, sports
equipment)
4
Battery pack
check every half
month after use
check every half
month after use
check every half
month after use
check every
month after use
