Bras FBM L Gebrauchsanweisung Seite 16

FBM L / LS
outer side up and off the hook located on the opposite side
(see figure 6).
3 - Remove the bowl by lifting its faucet side up and off the
fastening hooks (see figure 7) and slide it out (see figure
8).
4 - Slide the outer spiral out (see 4 -) and then the inside
16
figure 6
figure 7
figure 8
auger (see figure 10).
5 - Remove the bowl gasket from its seat (see figure 11).
6 - Dismantle the faucet assembly (see figure 12).
7 - Slide the drip tray out and empty it.
figure 9
figure 10
figure 11
figure 12
Bras Internazionale spa
