1. Battery charging
Connect the charger to the AC supply (100-240V AC, 50/60Hz).
Charging
Fully charged
Socket
Bottom of
charging stand
Adapter
Charging stand
and battery
2. Battery replacement
click
Open the battery back cover Insert the battery diagonally into
the battery compartment and
withstand the front end
3. Button and Operation
Left start button Right start button
Multi-functional
switch
Operation Photo Instructions
Push forward and hold the
1s
Power on
multi-functional switch for 1 second.
Push forward and hold the
3s
Power off
multi-functional switch for 3 seconds.*
Press the left and right start buttons at
Start operation
with two hands the same time to run the device
Speed When the device is powered on, push
Short toggle switch
switching forward and then release the
multi-functional switch
mode 1
1. When the power is on, push forward
and then release the left and right start
Speed 2 press
buttons at the same time to keep
switching
device operating.
mode 2
2. Release the right start button and
then quickly press it twice and hold on*
When the device is powered on but not
Manual
2 press in operation condition, double click the
operation
left start button twice or set it via
switching
SublueGo App
Left hand
1. Manual operation to L left hand mode
operation of
2. Press the start buttons with two hands
one-hand
3. When the device operates, release the
operation right hand
Right hand
1. Manual operation to R right hand mode
operation of
2. Press the start buttons with two hands
one-hand
3. When the device operates, release the
operation
left hand
Before using one-hand operation function, the user must make
sure he/she has professional diving skill and understand the
operation process and usage notice of one-hand operation
mode in the WhiteShark™ Navbow User Manual well, as well as
+
completely mastering the operation in absolutely safe water
environment before using the product.
When the battery level is less than 50%, you cannot enter the
TURBO speed.
The speed switching mode 2 can only be available under
two-hand operation mode.
* The product will automatically be powered off after 20 minutes
without any operation.
Wear and Emergency Release of Anti-lost Lanyard
Wearing is finished Quick release
While wearing the anti-lost lanyard, in order to protect your
personal safety in case of emergency, the device can be
separated from you by quick release.
One-hand Operation
The one-hand operation function helps the user release one hand
when operating the underwater scooter, so that the user can
balance ear pressure, call companions and do other activities.
1 2 3
Install D-button Connect one-hand Connect submarine
transfer buckle operation sling suit waistband*
4 5 6
Regulate it to the For underwater When it is smoothly
best length operation, start operated, release
according to your operation with two your non-operation
arm length hands and let one hand hand and change
operate the sling to be to one-hand
straightened under operation
pressure
Please strictly follow the operation method in Sublue instructions
for one-hand operation. Do not try other methods because they
may cause unknown physical risks.
The user must possess professional diving skill and understand the
operation process and usage notice of one-hand operation mode
in the WhiteShark™ Navbow User Manual well, as well as
+
completely mastering the operation in absolutely safe water
environment before using the product.
Please firstly adapt and exercise the one-hand operation under
FREE mode.
When operate the device under water, please start operation with
two hands. When it is smoothly operated, use one-hand operation
to straighten the sling. You should not release your non-operation
hand until your hand tension is significantly reduced. After that,
you can operate with one hand.
4. Description of Display Screen
Screen Interface
Compass
Depth
(Beyond setting warning)
Temperature
(Beyond temperature
Battery remaining power
range reminder)
(Low cbattery warning)
Speed level
Bluetooth connecting state
One-hand/two-hand
Exercise data record reminder
operation mode
Display of main screen information
Information Photo Status Instructions
Battery
light
continuous
Low battery When the remaining battery
Flash
warning is 30%
Extremely low Rapid
When the remaining battery
battery warning
Flash is 20%
000°
S
light
Compass
00.0
m
Depth*
light
30.0
Depth
Needs to be started in SublueGo
m
Flash
pre-warning note
where functions are set
00.0
℃
Temperature light
Temperature beyond ℃
Flash
span upper limit
℃
Temperature beyond
Flash
span lower limit
FREE
light
Low speed of about 1m/s
SPORT
Speed gear* light Medium speed of about 1.5m/s
TURBO
High speed of about 2m/s
light
Mobile phone and device are
light
not connected
Connection
condition
Mobile phone and device are
light
successfully connected
