STEINEL US 360 KNX Bedienungsanleitung Seite 10

Detection zone
DualTech / US 360, mounting height 2.8 m
DualTech
PIR radial and presence detection
PIR tangential detection
US tangential and presence detection
US radial detection of substantial movements
US 360
US tangential and presence detection
US radial detection of substantial movements
Electrical installation / automatic mode
The wiring leads selected for
installation must comply with
the regulations laid down in
VDE 08 29 (DIN EN 5000 90)
(see Safety precautions, page 9).
Single US / Dual US, mounting height 2.8 m
Single US
Dual US
- 10 -
