Transmitter programming procedure

Transmitter programming procedure
The operating instructions provided with receivers and other trans-
mitters must be complied with at all times.
1.)

Programming the i-R Light Sensor

1.1) With learnt in transmitter or prgramming button on the
receiver
P ress the PROG button on the receiver or a programmed trans-
mitter for 3 seconds (wait for confirmation: brief upwards and
downwards movement of the motor). The receiver remains in
programming mode for 1 minute. Briefly press (1 sec.) the PROG
button of the sensor. The sensor has now been programmed.
Transmitter or
receiver
3 sec.
1.2) Without programming button, if no transmitter is learnt in
yet
Connect the receiver to the electric power supply.
I mportant: Please connect only a receiver that has not learned
a transmitter permanently to the power supply system.
P ress the PROG button of the i-R Light Sensor for 3 seconds
(wait until the control light flashes once). The sensor has now
been programmed.
i-R Light Sensor
3 sec.
Sensor
➡
25
1 sec.
