English
Description
The audio converter by Delock converts an analogue stereo signal into a
digital signal. Two cinch cables can be connected to the device to input the
analog source signal, e.g. from an MP3 player. At the output, the signal can
be transmitted either via optical TOSLINK connection or via S/PDIF coaxial
connection.
Technical details
• Connectors:
Input:
2 x RCA female
1 x DC jack
Output:
1 x TOSLINK female S/PDIF
1 x Coaxial female S/PDIF
• Sample rate: 16 Bit / 48 kHz
• Robust metal housing
• Dimensions (LxWxH): ca. 63 x 41 x 21 mm
Power supply specification
• Wall power supply
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.3 A
• Output: 5 V / 1 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.1 mm
outside: ø ca. 5.5 mm
length: ca. 9 mm
System requirements
• Analogue audio signal
• Connection cables
Package content
• Converter analogue > digital
• Power supply
• User manual
