To clean the device external parts always use a cotton cloth dampened with detergent. Don't use abrasive or solvent detergents.
PARTICULAR CARE SHOULD BE TAKEN TO ENSURE THAT THE INTERNAL PARTS OF THE EQUIPMENT DO NOT GET IN TOUCH WITH LIQUIDS.
During all clearing operations use protection gloves and apron (if need be, also wear a face mask and glasses) to avoid getting in contact with
contaminating substances (after each utilization cycle of the machine).
The ASPIMED 3.3 suction equipment does not need maintenance or lubrication.
It is necessary to check functioning and instrument before every use. Unpack the instrument and always check integrity of plastic parts and
feeding cable, they might have been damaged during previous use. Connect cable to electrical network and turn switch on.
Close the aspiration outlet with your finger and with suction regulator in maximum vacuum position check that the vacuum indicators reaches
-90 kPa (-0.90 bar) maximum. Rotate the knob from right to left and check the aspiration regulating control.
The vacuum indicator should go down -40 kPa (-0.40 bar). Verify that loud noises are not present, these can indicate wrong functioning.
A protection fuse (F 1 x 4A 250V) reachable from exterior and it situated in the plug protects the instrument.
For use replacing, always check the type and the range indicated.
Type of fault
1. No aspiration
2. No aspiration
3. The float doesn't close
4. The float doesn't close
5. Low suction
6. No aspiration due to flow
leakage of mucus
Faults 1 - 2 - 3 - 4 - 5 - 6
If the overfill security system it's activated, don't proceede with the liquid aspiration.
If the overfill security system doesn't work there are two cases:
1° case – If the overfill security system doesn't work the aspiration will be stopped by the bacteriological filter who avoid the liquid penetration
inside the device.
2° case – If both the security system doesn't work, there is the possibility that liquid comes inside the device, in this case return the device to
MORETTI technical service.
BEFORE EVERY CHECKING OPERATION, IN CASE OF ANOMALIES OR BAD FUNCTIONING, PLEASE CONTACT MORETTI
TECHNICAL SERVICE.
MORETTI DOES NOT GIVE GUARANTEE IF INSTRUMENT, AFTER THE TECHNICAL SERVICE CHECKING, APPEARS TO BE
TAMPERED.
The filter is produced with (PTFE) hydrophobic material witch prevents fluids entering the pneumatic circuit. When the filter is wet, it's not possible
to use the unit therefore the filter should be changed immediately. In case of possible contamination or discolouration, change the filter
immediately.
Don't use the suction unit without the protection filter fitted. If the suction unit is used in an emergency or in a patient where the risk of
contamination is not know the filter must be changed after each use. Available under request with different versions with complete jar 2000cc.
The suction probe must be changed at the end of each application.
WARNING: Suction tubes for insertion in the human body purchased separately from the machine should comply with ISO 10993-1 standards
on material biocompatibility.
CLEANING THE MAIN UNIT
NEVER CLEAN THE EQUIPMENT WITH WATER.
PERIODICAL MAINTENANCE CHECKS
Cause
Jar Cap badly screwed down
Lid seal not in its seat
If the cap has been washed, ensure that
the float is not partially detached
The float it's covered by dirty material
Foam inside the jar
Filter blocked
None of the remedies has achieved the
desired results
ACCESSORIES SUPPLIES
DESCRIPTION
Nr. 2 COMPLETE ASPIRATION JAR 2000cc
CONICAL FITTING
TUBES SET 8mm x 14mm (TRASPARENT SILICON)
ANTIBACTERIAL FILTER
FOOTSWITCH CONTROL cod. 52130
(for versions equipped with footswitch control)
Remedy
Unscrewed the cap, then rescrew it correctly
Unscrew the cap and insert the seal properly in its seat
Insert the float into it's place
Unscrewed the cap, leave the and put in on autoclave
Fill the jar to 1/3 full of ordinary water
Replace filter
Contact the seller or MORETTI After-sales Assistance
Service
