filtering facepiece, aligning the corresponding joints with each other 3) Push
and rotate the Active Shield (a) clockwise until the end stop is reached.
POWER ON / 1) Press the button (short press). 2) The status LED lights up
white. Note: If the status LED flashes rapidly when the power is turned on
it means that the Active Shield battery is getting low but there is still some
battery life left. We suggest connecting it to a charging source (see Charging
chapter). If the status LED flashes rapidly and then the Active Shield turns off,
it means the battery has been discharged. Connect to a charging source (see
Charging chapter).
USE / When turned on, the Active Shield is in automatic mode: the fan auto-
matically adjusts according to your breathing rate (status LED flashes white
color).
POWER OFF / 1) Press the button for 3 seconds (long press). 2) The status
LED goes out. Note: turn off the device when it is not in use to prolong
its useful life
RECHARGE / To charge the Active Shield, lift the USB-port cover tab and
connect a USB-Micro cable to the charging port (use a standard charger for
smartphones or electronic devices or plug it into the charging station. Always
check the voltage, do not exceed 5V). Important: upon completion of
charging, be sure to properly close the USB port cover tab to ensure proper
operation of the product and its degree of protection.
Rechargeable Battery: Capacity: 800 mAh / Voltage: 3.7V / Charging
dura-tion: +/- 3hr / Usage time on single charge: + 7hr. Note: indicative figure
taken during the combined use of speeds. With exclusive use of maximum
speed, the duration will be shorter.
Status LED (charge indicator): Flashing green: charging / Static green: full
charge. Note: fully charged, after few minutes the LED will go out. Incorrect
connection of the charger could cause serious damage to the device.
Damage caused by improper use is not covered by the warranty. To prolong
battery life, it is recommended to disconnect the charger from the device after
charging is complete.
12
