ASSEMBLY
The following assembly work must be carried out before the first
operation:
1.
Installation of the wheels.
2.
Installation of the steering wheel.
3.
Installation of the driver's seat.
4.
Assembly of the discharge flap on the blades
Attention!
Putting into operation (even test operation) before complete
assembly is strictly forbidden - dangers of accidents!
The information on directions (right, left, top etc.) for this appliance
are to be understood in the direction of travel looking from the dri-
ver's seat.
The order of assembly steps is to be complied with, as otherwise
flawless function cannot be guaranteed.
Please note:
The figures stated to the left of the text, such as the
here, refer to the illustrations in the illustrated part at
the front.
Front wheels:
Lock both front wheels.
6
Lift tractor slightly by bumper and pull to front wheel.
7
Push washer toward wheel rim.
Insert lock washer into shaft groove before washer and
8
press down.
2x lock washer dia. 15x29x1.5 - contained in screw/bolt
bag.
9
Fit cover cap.
Rear wheels:
Lock both rear wheels.
Move tractor to rear wheel until rear wheel is heard to strike
10
steering knuckle.
11
Wheel axle protrudes from rim.
O-ring Ø11 x 2.6 is fitted in the works -
12
(secures the parallel key).
GB
Remove O-ring - do not re-use
13
Fit one washer
14
each on axle - first 19 mm dia. x 26 mm dia.!
Insert lock washer in shaft groove and press down.
15
Fit cover cap.
16
Assembly of the steering wheel
Point the front wheels straight ahead in the direction of
17
movement.
Push the 8 x 60 Ø clamping sleeve about 10 mm into the
bore of the steering wheel hub.
Put the steering wheel onto the steering column.
Ensure the correct position: the spoke is to point towards
the driver's seat.
5
Put the round iron (7 x 150 mm Ø) of the enclosed spark
plug connector into the free bore of the steering wheel hub.
Turn the steering wheel until the round iron can be pushed
through the bore of the steering wheel.
Connect with steering wheel with the steering column by
pushing in the 8 x 60 Ø clamping bolt.
Installing the driver's seat
Insert the driver's seat into the guide of the hinged
18a
console
Press the adjusting spring
backwards.
Let go of the adjusting spring at the required position and
allow the seat to engage.
The seat can be adjusted by 2 cm at a time to 5 positions.
Securing the driver's seat against being pul-
led out.
Hinge the driver's seat upwards.
18b
Completely screw in the M 4 x 16 self-tapping oval-head
screw (Philips).
GB11
1x 19 mm dia. x 26 mm dia. and
1x 20 mm dia. x 42 mm dia.
.
upwards and push the seat
