Franke Mythos Water Hub
Franke Mythos Water Hub can only be connected to
designated electronic taps from Franke with
a compatible software version.
Check the details in the "Installation manual",
page 6.
General specifications
Dispensing water types
Operation
Parametrization
Minimum installation dimensions
Weight netto (empty)
Weight netto (filled)
Supply voltage
Load
Plug
Max. power consumption
Standby power consumption
Sound pressure level (free- standing)
IP rating
Certifications
Filtered chilled water
Volume of reservoir
Cooling principle
Temperature control range
Flow rate w/o compensator
Cooling time
Connections
For the installation of Franke Mythos Water Hub,
a mains water connection and a GFCI-protected
separate power circuit with a suitable mains
connection fused by at least 10 A and a permanent
voltage supply of 220-240 VAC / 50 Hz are
necessary. Angle valves must already be installed.
Filtered chilled water
Filtered carbonated water
Filtered ambient water
Filtered boiling water
Operation via electronic tap
Parametrization via app (BLE)
Height > 440 mm
Width > 200 mm
Depth ≥ 550 mm
20 kg
27 kg
220-240 VAC / 50 Hz
7.5 A
EU-version = Type 303A acc. to CEE7
UK version = Type G / BS 1363 British 3 Pins
All in One: 1725 W (±10%)
Sparkling: 230 W
All in One: 19 W (cooling & boiling on)
Sparkling: 5.5 W (cooling on)
37 ± 4 dB in operation mode 0 dB in standby mode
IPx1
CE-UKCA
2.2 l
Tank-in tank setup
approx. 4-10 °C, not adjustable
approx. 2.5 l/min @ 3 bar
∆T = 10 K in 8 minutes (from 20°C to 10°C)
(25 °C to 5 °C: approx. 35 minutes)
