Settings on the C24 module in the MELSEC PLC
system
AJ71(U)C24
Station number:
When communicating with the E-series: 0
Mode setting:
When communicating with the E-series: A
Setting of the switches:
Default
comm.
Switch settings in
E-series
software
SW11 ON Main channel
settings
SW12 ON Data length
SW13 OFF Transmission
speed setting
SW14 ON
SW15 ON
SW16 OFF Parity check
SW17 OFF Parity setting
SW18 OFF Stop bit
SW21 ON Sum check
SW22 ON Write during
RUN
Position of setting
switch
Setting items
ON
RS-422 RS-232C
8 bits 7 bits
Refer to the table below
Enabled Disabled
Even Odd
2 bits 1 bit
Enabled Disabled
Enabled Disabled
Notes
OFF
Valid for
modes A to D
–
–
–
Valid only
when SW16
is ON
–
For dedi-
cated protocol
C-1
