Beijer Electronics E50 Installationsanleitung Seite 86

Parameter
Keyboard material/
Front panel
Reverse side material
Weight, excl. D-sub
Serial port RS422
Serial port RS232C
Expansion slots
Flash memory for application
Real time clock
Current consumption at
rated voltage
Display
Active area of display, WxH,
mm
Contrast setting
Supply voltage
Fuse
Ambient temperature
Storage temperature
A-6
E700
Membrane keyboard with Autoflex EB A180 or Polyes-
polyester snap discs. Over- ter on glass and Autotext
lay film of Autotex F207 with F207.
print on reverse side. 1 mil- Touch screen. 1 million
lion operations. See Appen- operations.
dix D. See Appendix D.
Yellow-chromated steel plate
1.7 kg
25-pin D-sub contact, chassis mounted female with stand-
ard locking screws 4-40 UNC.
9-pin D-sub contact, chassis mounted male with standard
locking screws 4-40 UNC.
2 2
400 kb 400 kb
±10 PPM + error because of ambient temperature and
supply voltage. Total max error 1 min/month = 12 min/year.
Minimum life: 10 years of the battery for the real time
clock.
Without load: 300 mA
Max load: 550 mA
LCD (liquid crystal display), LCD (liquid crystal display),
320x240 pixel, 256 colors, 320x240 pixel, 256 colors,
graphic and text. Back light: graphic and text. Back light
lifetime 25000h at the ambi- lifetime: 25000 h at the
ent temperature of +25°C. ambient temperature of
CFL. +25°C.
Touch screen. CFL.
115.2 x 86.4 115.2 x 86.4
Programmable
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements
for SELV or PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements
for class 2 power supplies.
1 AT, Littelfuse R452 001 (Nano
mAT, 5 x 20 mm.
0° to +50°C
-20° to +70°C
E710
2
SMF Slo-Blo) or 800
