S-idee V913-A Benutzerhandbuch Seite 24

7.CALIBRATION OF THE GYROSCOPE
8.UNLOC/KLOCK THE AIRCRAFT
9.ONE-CLICK TAKE-OFF/LANDING
10.EMERGENCY STOP
11.SWAP LEFT AND RIGHT HANDS
12.FLIGHT ADJUSTMENT AND SETTING
Mode
Aileron
Lifting/
front
and rear
After aligning the code, place the aircraft on a flat ground, and then press the
two joysticks of the remote control to the bottom left corner at the same time
for about 1 second. At this time, the indicator light on the aircraft flashes,
release the joystick, and the aircraft indicates The light is always on to indicate
that the calibration is complete.
Note! The aircraft must be placed on a flat ground during calibration!
After the code is aligned, the two joysticks of the remote control hold the outer
or inner horoscope for 1 second to unlock the aircraft. After unlocking, push
the throttle and the plane will take off and hover about 1 meter.
Press the button on the upper right corner of the remote control and the
aircraft will take off automatically, then rise to about 1 meter and hover. After
pressing the button, the aircraft automatically landed on the ground and the
motor stopped.
In an emergency, press the buttons on the left and right upper corners at the
same time, and the aircraft motors will stop immediately.
Note! When the aircraft is flying at high altitude, do not press emergency stop
in non-emergency situations.
Push and hold the button next to the left-hand joystick, and then turn on the
power switch at the same time. After turning it on, release the button to switch
between left and right hands.
llustration
Move left Move right
Fly forward Fly backward
Mode
Throtle
Rudder
- 23 -
llustration
Ascent
Descent
Turn left
Turn right
