Mounting
1.
Attach the two grille side panels (3) to the grille centre panel (1) using the eight
double plastic clips (7) in the width required for the vehicle.
Tip: Position the grille as centrally as possible in the vehicle. Leave a
safety distance of at least 1 cm between the grille side panel and the
vehicle side window.
2.
Insert the four single-plastic clips (2) into the side of the four connector holders
(8). Make sure that the openings of the clamps face in the same direction as the
connection holders (8).
3.
Attach two connection holders (8) to each telescopic pole (5).
4.
Screw the two threaded bolts (4) into the lower opening of the telescopic rods (5)
up to approx. 3/4 of the way.
5.
Insert the plastic feet (6) on top and bottom of the telescopic rods (5).
6.
Attach the telescopic rods (5) to the grille centre panel (1) using the already fitted
connection holders (8) and the single plastic clips (2).
7.
Place the assembled partition grille in the position provided in the boot or directly
on the backrest of the rear seat, extend the telescopic rods (5) to the required
height and secure firmly in the boot using the thumb screw and the threaded bolt.
8.
Finally, align the height of the grille and fix it to the four connection holders (8)
using the screws.
9
