GB
PDC 18-4 Compact
LED green – lit continu-
ously: charged > 60 %
LED green – flashing
slowly: charged 30 % – 60
%
LED green – flashing
quickly: charged 0 % – 30
%
LED yellow – lit continu-
ously: battery is empty
LED red – lit continu-
ously: battery temperature
is outside the permitted
range.
LED red – flashing: indi-
cates a general fault, e.g.
incomplete contact, short
circuit, battery pack faulty,
etc.
7
Settings
WARNING
Risk of injury
Always switch off the machine before ad-
justing settings!
7.1
Changing direction of rotation
[1-7]
• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise ro-
tation
7.2
Changing gear
You can change gear using the gear switch
[1-5].
7.3
Adjusting the torque[1-6]
Fastening
Select the correct torque setting:
Position 1 = low torque
Position 12 = high torque
An acoustic signal sounds when the preset
torque is reached and the machine then
switches off. You must release and press the
ON/OFF switch [1-8] again to start the ma-
chine.
Drilling
Mark is aligned with drill symbol
mum torque.
All manuals and user guides at all-guides.com
= maxi-
7.4
Impact drilling
The machine was designed for impact
drilling into tiles, masonry and stone.
Set the selector switch [1-4] to the hammer
symbol. Set the adjusting wheel [1-6] to the
drill symbol.
7.5
Changing tools
Turn the clamping sleeve [5-1] anticlock-
wise to open the jaws. The arrow on the
clamping sleeve indicates the opening direc-
tion. The tool can now be inserted into the
drill chuck.
CAUTION
Risk of injury
Clamp the tool centrally in the drill chuck!
Turn the clamping sleeve [5-1] clockwise to
clamp the tool securely
8
Working with the machine
8.1
On/Off switch [1-8]
Press = ON, release = OFF
The speed of the machine depends on
how far the on/off switch is pressed in.
8.2
Bit depot [1-1]
Magnetic, for storing bits and bit holders.
8.3
Belt clip [1-9]
The user can attach the machine to work
clothing for short periods using the belt clip
(right/left).
8.4
Acoustic warning signals
Acoustic warning signals sound and the ma-
chine switches off in the following operating
states:
– Preset torque reached.
– "Block protect" - starting torque too
peep
high.
– Machine overloaded
9
Service and maintenance
Note the following information:
– Keep the ventilation slits on the machine
free and clean to ensure adequate cooling.
– Keep the contacts on the machine, charger
and battery pack clean.
12
