Usb Operation; Auxiliary Input - Soundmaster Rcd1870Sw Bedienungsanleitung

1. Connect your USB drive with the USB port
2. Switch the unit on and select USB mode.
3. The operation procedures are the same as CD operation.
-Compatible storage device (up to 128GB, FAT32)
-Always connect your USB flash drive directly to the USB port without USB extension cable.
-Due to some USB drive manufacturer's non-compliance with the full USB 1.1/2.0 standard. A
small percentage (about 5%) of USB flash drive might not be compatible.
Connect an external audio source like an MP3 player using a 3.5mm audio cable (not supplied).
1. Connect one end of the cable to the external device headphone output and the other end to
the AUX socket at the backside of the unit.
2. Switch the unit on and select AUX mode
3. Starts playback and adjust the volume on the external audio source e.g. MP3 player.
There is a headphone output jack at the backside of the unit. If headphones are
connected to this socket for private listening, the speakers will switch off.
Note: Adjust the volume lever lower during the PHONES operation.
To prevent possible hearing damage, do not listen at high volume levels for long periods.
This unit can switch to standby automatically after a preset period.
When the unit is turned on, press and hold "MENU/INFO" 2 seconds and enter to [System]
menu, select [Sleep] then press "OK" to access.
Press " " button repeatedly to select the sleep timer period (Sleep timer Off, 15, 30, 45, 60,
90 minutes) and confirm with "OK"
1. Press and hold "MENU/INFO" 2 seconds to enter menu to select [System] > [Time], then
press "OK" button for confirm.
2. In the TIME menu, you select by unsing "
[Set Time/Date]: set the current time and date.
[Auto update]: Update from Any/ Update from DAB/ Update from FM/ No Update
[Set 12/24 hour]: Set 12/24 hour
[Set date format]: DD-MM-YYYY/ MM-DD-YYYY
3. Press "OK" to save setting, press " " button to previous step or press "MENU/INFO" to exit.
Note: If the system is idle for 30 seconds, it exits time setting mode automatically.
For time setting, during standby you can press and hold " " 2 seconds for open the time setting
menu also.

USB OPERATION

AUXILIARY INPUT

HEADPHONES
SLEEP
TIME
" below options:
6
RCD1870 / English Instruction Manual
