Fronius Primo GEN24 Plus Schnellstartanleitung Seite 8

LG FLEX
12
NOTE!
Earth (PE) can
be connected
to the inverter.
Setting up Terminating Resistor
15
Steps 9a / 9b
Modbus 0 / 1
(min. CAT 5)
max. 300 m
17
LG RESU Monitor
Connecting BPU
10
13
Modbus 1 0 1
Modbus 0
0 1
Modbus 0 / 1
(min. CAT 5 STP)
18
LG RESU Monitor
< 30 m
11
14
Closing & Commissioning
16
19
Connect to RMD
GUIDE
1. Make sure Battery is on.
RESU_MAC ADDRESS
2. Click the „Turn on WiFi" button to access the
system WiFi interface.
3. Turn on WiFi and look for RMD* or RESU_*
Secured
(* represents the last 12 digits of the device
serial number).
4. Please enter a password
5. Go back to the Apps screen and make sure
your WiFi is connected.
Password:
6. Click the „Connect to RMD" button to access
the RMD.
MAC ADDRESS1234 7. If the RMD connection is successful, click the
NEXT button.
BACK
Turn on WiFi
NEXT
