Teileliste
Nr.
Bezeichnung (ENG)
1
Right upright
2
Left upright
3
Backrest cushion frame
4
Seat pad frame
7
Adjusting handle
8
Fixed axle
9
Torsion spring
10
Limiting screw
11
Semi-sliding sleeve
12
Elliptical tube stopper
13
Rubber mat
14
Upper protecting jacket
15
Lower protecting jacket
16
Left extend jacket
17
Middle extend jacket
18
Right extend jacket
19
Left hook jacket
20
Middle hook jacket
21
Right hook jacket
22
Foot protecting jacket
24
Plug
25
Split washer
26
Small countersunk head rivet nut
27
Plain washer
28
Hex socket head cap screw
29
Nylon insert lock nut
30
Cross head modifi ed truss head screw
31
Plain washer
32
Spring washer
33
Hexagon socket button head screw
22
Spezifi kation
d=6
M8*18
Φ24*Φ13*2.5
M12*110
M12
M5*12
Φ16*Φ8.4*1.6
M8
M8*40
Studio Incline Bench
Anz.
1
1
1
1
1
1
1
1
2
2
3
2
2
2
2
2
2
2
2
2
2
2
6
8
4
4
32
14
14
4
