Heater hook-up
Thermo S
Connect the Spheros Thermo Test diagnostic adapter directly to the separate
3-pole connector located at your heater's wiring harness.
24V
BUSY
PC
S p h e r o s T h e r m o T e s t
to vehicle
Fig. 16: Heater hook-up: Thermo S
50
approx. 3m
(9.8')
Cable
SPHEROS Thermo Test
Thermo S
until 11/2012
Thermo S
as from 11/2012
