Spheros Thermo Test Betriebsanweisung Seite 53

SPHEROS Thermo Test
GBW 300
Connect the Spheros Thermo Test diagnostic adapter directly to the control device.
approx. 3m
to vehicle
Fig. 15: Heater hook-up: GBW 300
24V
BUSY
PC
S p h e r o s T h e r m o T e s t
(9.8')
Cable
Adapter Wiring Harness
Control device
Connector adapter
Heater hook-up
GBW 300
49
