PROFILER SCD
Configuring the position correction yourself
X
9 10
As an example, the position correction
is performed for the X-axis within the
following steps.
1 Open the menu Setup.
2 Open the menu Origin 1/3.
6
3 Enable the function Zero position
3
4 Enable the desired function for set-
4
5
5 Make sure that the function Offset
6 Save your entries with
7 Quit the menu Origin 1/3 with
8 Open the menu Encoder 1/2.
9 Enable the REF check box.
11
10 Disable the Corr check box.
11 Save your entries with
12 Quit the menu Encoder 1/2 with
13 Quit the menu Setup with
value with button.
ting the machine zero (Märzhäuser
measuring stage: Set machine zero
with reference switch).
from machine zero is disabled.
switch to the position display.
Operation
.
.
.
.
to
143
