Fiche technique FR PNT15 Original instructions Panther T ..12 ..15 ..18 ..21 ..23 ..25 ..28 ..30 ..33 ..36 ..39 ..42 Airchaud Diffusion - 35 route de Colmar, 67600 Sélestat contact@airchaud-diffusion.fr...
Seite 2
Fiche technique FR PNT15 Panther T Panther T 13,5-15 kW (PNT135, PNT15) ø7 ø14 ø6,5 Panther T 20-30 kW (PNT20, PNT30, PNT305) ø8,5 ø15 ø9 Minimum mounting distance Wall 30° 1800 1000 Floor Ceiling FR: Distances minimales DE: Mindestabstand SE: Minimiavstånd...
Seite 3
Fiche technique FR PNT15 Panther T Mark and drill holes Detach bracket from the unit Mount the bracket on the wall Hang the unit on the bracket Tighten all screws Adjust the angle and fasten with screws PNT135/15: 0° - 7,5° - 15°...
Seite 4
Fiche technique FR PNT15 Panther T Connection PNT15 PNT135 PNT15 PNT135 400V3~ 400V3~ 500V 440V 500V 230V3~ 440V 230V3~ 500V 6.3A x 2 230V 630mA x 1 440V 500V 6.3A x 2 230V 630mA x 1 440V PNT20 PNT30 PNT20 PNT30 6.3A x 2...
Seite 5
Fiche technique FR PNT15 Panther T PNT305 6.3A x 2 500V 230V 440V Resetting the overheat protection FR: Réinitialisation de la protection anti-surchauffe DE: Zurücksetzen des Überhitzungsschutzes SE: Återställning överhettningsskydd NO: Tilbakestille overopphetingsvernet DK: Nulstilling af overophedningsbeskyttelsen FI: Ylikuumenemissuojan palauttaminen NL: Resetten van de oververhittingsbeveiliging ES: Reajustar la protección contra el...
Seite 6
Fiche technique FR PNT15 Panther T Accessories Item Type Used for HxWxD number [mm] 10274 PLR15 PNT135, PNT15 355x355x60 10275 PLR30 PNT20, PNT30, PNT305 415x445x60 PLR15/30 Controls for installations not covered by the Ecodesign Regulation (EU) 2015/1188 The fan heater must be supplemented with a control panel PP.
Seite 7
Fiche technique FR PNT15 Panther T Panther T (IP44) Item Type Output Airflow Sound Sound ∆t* Motor Voltage Amperage Weight number steps power * pressure* [kW] [m³/h] [dB(A)] [dB(A)] [°C] [kg] 400V3N~* 21,7 334023 PNT15 0/7,5/15 900/1300 61 39/47 50/35 230V3~...
Seite 8
Fiche technique FR PNT15 Panther T ) Ljudeffekt (L ), mätningar enligt ISO 27327-2: 2014, Installationstyp E. ) Ljudtryck (L ). Förutsättningar: Avstånd till aggregat 3 meter. Riktningsfaktor: 2. Ekvivalent absorptionsarea 200 m². Vid lägst/högst luftflöde (när tillämpligt). ) ∆t = temperaturhöjning på genomgående luft vid maximal värmeeffekt. Vid lägst/högst luftflöde (när tillämpligt).
Seite 10
Fiche technique For installations not covered by ECO Design regulation (EU) 2015/1188 FR PNT15 For installations not covered by ECO Design regulation (EU) 2015/1188 Panther T Note Remove the two internal fuses 6,3A in the secondary units 11 1213141516 PNT 15 / 135...
Seite 12
Fiche technique FR PNT15 Panther T Consignes de montage et mode d'emploi Généralités L’alimentation de l’appareil doit être Lisez attentivement les présentes consignes déconnectée durant tous les travaux avant d'installer et d'utiliser l'appareil. d’entretien, de réparation et de Conservez ce manuel afin de pouvoir le maintenance.
Seite 13
Fiche technique FR PNT15 Panther T Entretien PNT15, PNT135 – Réglage d’usine Les moteurs du ventilateur et les autres 15 16 organes de l'appareil ne nécessitant aucune maintenance, seul un nettoyage régulier est nécessaire. La fréquence de nettoyage dépend PNT20, PNT30, PNT305 –...
Seite 14
Fiche technique FR PNT15 Panther T Sécurité • Un disjoncteur à courant résiduel de 300 mA doit être utilisé contre les risques d'incendie dans les installations de produits avec chauffage électrique. • Veiller à ce que les zones à proximité des grilles de prise et de sortie d'air soient libres de tout objet susceptible de provoquer des obstructions.
Seite 15
Fiche technique FR PNT15 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net Airchaud Diffusion - 35 route de Colmar, 67600 Sélestat contact@airchaud-diffusion.fr Tél. : 03 88 08 67 05 SIRET : 444 448 898 00015 www.airchaud-diffusion.fr...
