Please read the manual carefully. This prevents failures and complaints!
1. Delivery
The Aqua Medic reverse osmosis units are compact and highly efficient units. They consist of the
following parts:
- sediment pre-filter with 5 m pore size
- activated carbon pre-filter to get rid off chlorine in the tap water
- reverse osmosis module with a first class synthetic membrane (Polyamide/Polysulfon, TFC) which
has the following capacity:
Reverse osmosis unit
Easy Line 150
Easy Line 90
- Flow restrictor: at this valve, the permeat/concentrate ratio is adjusted to 1:4.
- Tap water connection fitting with 3 m pressure tube
- Hose's plug
- Wall bracket (2 pcs.)
- Connecting clip between pre-filter and reverse osmosis module (4 pcs.)
Litre/Day
110 - 150 l
75 – 90 l
Fig. 1:
1. Water inlet
2. Sediment filter
3. Ativated carbon filter
4. Reverse osmosis module
5. Pure water outlet
6. Waste water outlet incl. flow
7. Module's screw cap
8. Membrane
9. O-Ring
10. Hose's plug
11. Flow restrictor
restrictor
