CV Programming
CV programming must be done on the programming track.
We recommend creating a fictitious locomotive for programming
purposes. Values in parentheses are the factory settings.
The turnout lantern connected to the digital installation decoder
will blink as a control check during the data transmission.
The programming can be done optionally with fx (MM) or DCC.
In fx (MM), we recommend setting the address by means of DIP
switches (see 39ff).
fx (MM)
Before doing any programming, the turnout to be programmed
must be switched with the Keyboard. After that the CVs are
changed immediately with the Control Unit or the CV configu-
ration on the Central Station. Immediately after that, switch the
newly programmed turnout again with the Keyboard. At this
point the programming is accepted and is functional.
CV Meaning
8
Decoder reset
36 Turnout lantern
off/on
The procedure for programming with the 6021 Control Unit is the
same as locomotive programming (www.maerklin.de -> Service
-> Technische Informationen).
Values
8
(-) factory setting, not written
value is
0-1 (1)
DCC
CV Meaning
1
Address, lower value
Byte
7
Manufacturer version
number (software
version)
8
Manufacture recognition
ID Decoder reset
9
Address, higher value
Byte
29 Configuration
Bits 0-4 are not used
Bit 5: Decoder type
Bit 6: Addressing method
Bit 7: Decoder type
36 Turnout lantern, off/on
Setting and generating addresses larger than 255:
Example: Address 1044 -> 1044:256=4,078125 . The value before
the comma (4) is to be entered in CV 9. The value after the com-
ma (0,078125) is multiplied by 256, 078125x256=20. The value of 20
that is generated must be entered in CV 1.
Values
0-255 (1)
(-) read only
(131)
read only,
8
(-)
factory setting, value
is not written
0-7
(0)
(192) read only
0
0 / 32 basic or advanced
accessory decoder
decoder or output
0 / 64
address
128 accessory decoder
0-1
(1)
9
