Normal Use
• This digital installation decoder is designed for installation in
Märklin and Trix C Track turnouts with a turnout mechanism
(exception: Märklin three-way turnout).
• This digital installation decoder may only be connected to
Märklin or Trix switched mode power packs for external
power supply.
• This decoder may only be used in dry areas indoors.
Contents as Delivered
1 digital installation decoder
1 cable – yellow, red, and brown (for Märklin C Track)
1 cable – blue, red, and white (for Trix C Track)
Installation instructions
Warranty card
Additional tools required for installation: tweezers and soldering
station for a maximum soldering temperature of 30 watts /
300˚ Celsius / 572˚ Fahrenheit with a fi ne point, Electronic solder
(0.5-1 mm dia.), desoldering braid or desoldering pump.
Safety Notes
• IMPORTANT! This product has sharp edges and points related
to its function.
• Do wiring and assembly work only in a voltage-free work
environment. Otherwise you may experience electrical current
dangerous to the body leading to injury.
• Operate this decoder only with the permissible voltage
(see technical information).
When using a solder station there is the danger of burning
your skin.
Important Information
• Important: When installing the digital installation decoder,
try to avoid touching components on the upper side of the
decoder. Static charge can affect the function of the decoder.
• The operating instructions are a component part of the
product and must therefore be kept with the product,
particularly when it is given to another party.
• For repairs please see your authorized Märklin specialty
dealer.
• http://www.maerklin.com/en/imprint.html
Technical Data
• Load at lantern output
• Load at turnout output
• Voltage for the digital power circuit max. 20 volts eff.
• External voltage
• Electrical strength
≤ 100 milliamps
max. 2 amps
max. 20 volts DC
max. 40 volts
7
