4. Remove the bottom bracket (14) from the
thread on the underside of the housing (11).
Place the device with the two pins and the
thread on the white top of the pedestal (12)
and insert it into the recesses. Now attach the
housing to the base by screwing the bottom
bracket on the lower metal side onto the white
thread and fixing the base in this way.
5. Now set the device down correctly and start
assembling the fan head. First put the rear fan
grille (7) with the hole on the drive shaft of the
head and screw it down with the round grille
support (6).
6. Then take the 3-blade rotor (5) and place it
on the drive rod. Now fix the rotor with the rotor
holder (4).
7. Next, prepare the grille support (1) by
screwing it into a circle using the connection
screw and a screwdriver. (Only 2-3 turns)
8. Now place the front fan grille (3) exactly on
the edge of the rear fan grille (7) and now
place the grille support around the edge of the
