The charging
EXTERNAL POWERLAND AC/DC 48 V
BATTERY CHARGER
Important to know
No status of the charging process is shown in
•
the display of your eSchwalbe.
Always connect the charging cable to your
•
eSchwalbe first and then to the socket.
Reverse the order when disconnecting.
Never switch on your eSchwalbe while it is
•
charging as this may cause errors on the
screen. Always disconnect the charger first
and wait 60 seconds before switching your
Schwalbe back on.
Do not charge the batteries in rain. It is the
•
best to charge the batteries indoors.
Never disconnect the Anderson charging
•
cable before the charger is completely turned
off. Turn off the charger by disconnecting
the power cable from AC socket. It takes
10 seconds, then the status LED is off. Now
you safely disconnect the Anderson charging
cable.
Give your Schwalbe the power it needs
YOUR SCHWALBE IS EQUIPPED WITH AN EXTERNAL POWERLAND AC/DC CHARGER.
To ensure that your Schwalbe is charged correctly, you will find the individual steps for the charging process here:
01 02
Switch off your eSchwalbe Connect the charging cable
and remove the key from the to the Anderson plug in your
ignition. Wait 60 seconds. 2. eSchwalbe. You will find
the Anderson plug in the
compartment under the seat.
The LED light on the charger indicates the current status of the charging process:
A B
RED LIGHT: GREEN LIGHT:
Charging in progress Batteries are fully
charged
D E
GREEN FLASHING: NO LIGHT:
Connection is being
No AC input / AC
established and ready undervoltage
for charging
EN
03
Plug the power cable into
the socket. The charger
starts automatically once
connected to the AC socket.
C
RED FLASHING:
process fault
