16 • Produktinformation
Menü Untermenü
Funktion
168
Pressure type
169
Application
2
ALARM
21
Alarm Status
22
Alarm log
Reset
23
3
Service
31
Version no.
32
I/O
321
BURNER I/O
322
EXHAUST I/O
323
Draft input
324
Alarm relay
33
Options
331
Bearing cycle
332
Allow prime
333
Draft Input Delay
34
Factory reset
36
USB configuration
361
format USB
362
Data Log
363
Save config. file
364
Load config. file
365
Upgrade firmware
4
User Interface
41
Display
411
Language
412
Pressure units
413
LCD backlight
414
LCD contrast
Display
Beschreibung
PRESSURE MODE
Legt fest, ob die Steuerung für Auslass oder
Einlass arbeiten soll
APPLICATION
Sets if the control has to work as Exhaust
or Intake
ERROR
Der Fehler wird hier angezeigt
ERROR LOG
Die letzten 10 Alarme werden im System
gespeichert
RESET
Bei Auswahl Automatik wird der Alarm nach
15 Sekunden zurückgesetzt. Wenn "MAN"
Ausgewählt ist muss die Taste, "X" gedrückt
warden.
SERVICE
VERSION
Softwareversion wird angezeigt.
I/O-VIEW
AUX OUT XXX
In diesem Menü wird der Status der Kessel-I / O
AUX
IN XX
angezeigt. Durch Drücken der Taste können
die AUX OUT-Relais durch Drücken von oben
und unten aktiviert werden. Mehrere Aktivi-
erungen der -Taste wechseln von Relais 1 zu 6
EXH XTP x.xV OFF
XTP-, VFD- und VFD-Relaisstatus für Auslass
EXH VFD x.xV OFF
DRAFT INPUT ON/
Draft Input I/O status.
OFF
ALARM OUTPUT
Alarm relay output status.
ON/OFF
OPTION
BEARING CYCLE
Selecting "YES" will enable a bearing cycle on
present fans, if the boilers has not been active
for 24 hours.
Selecting a number from 0-250 will enable the
prime function. This allows the boilers to be
activated even though no sufficient draft is
present.
DRAFT INPUT DELAY The delay before the control goes into Fraft
Alarm
FACTORY
If "YES" is selected, a factory reset will be
performed.
USB CONFIG
FORMAT USB
Selecting "YES" will format the USB flash drive.
Notice! All data will erased!
DATA LOG USB /
Selecting "USB" will store the alarm log on the
INTERNAL
USB flash drive, "INT" will store the log in the
internal memory.
SAVE CONFIG FILE
Slecting "YES" provides the possibility to select
configurationfiles stored on the USB flash drive.
LOAD CONFIG FILE
Selecting "YES" will download the current
configuration to the USB flash drive.
UPGRADE
This function provides the possibility to
FIRMWARE
upgrade the firmware by means of a USB Stick
USER INTERFACE
DISPLAY
LANGUAGE
Language.
UNITS
Pa or inWC units.
LCD BACKLIGHT
LCD backlight turned on or not. The USE param-
eter will cause the backligt to be turned on if a
button is pressed.
LCD CONTRAST
3120075 20170830 DE EBC10v2
Klassifizierung
Standard
Positive or Negative
Negative
Exhaust / Intake
Exhaust
MAN / AUTO
AUTO
ON/OFF
ON
0-250 s / off
Off
0-20 s
0 s
YES/NO
NO
YES / NO
NO
USB / INT
INT
YES / NO
NO
YES / NO
NO
ENG / FRA / ESP
ENG
Pa / inWC
inWC
ON / OFF / USE
ON
10 – 100 %
50
