Omega 41000 Bedienungsanleitung Und Gebrauchsvorschriften Seite 12

SPARE PART DRAWING/ UNTERTEILENZEICHNUNG
TABLEAU DES PARTIES/ ONDERDELEN TEKENING
MODEL NO./ MODELL NR./ MODÈLE NR./ MODEL NR.: 41000 & 41001
Item Description
Pump Piston Assy.
1.
Foot Pedal
2.
3. Release Pedal
4. Handle Assy.
5. Filler Screw Assy.
6. Screw
7. Knob Assy.
8. Saddle Accessory
9. Saddle Assy.
10. Wheel Assy.
11. Air Motor Assy.
12. PU Pipe Assy.
13. Air Inlet Valve Assy.
14. Label (Not Shown)
15. Manual
16. Repair Kit
**Remark : The Repair Kit includes all the rubber seals, plastic seals, bushing and steel balls.
Umschreibung
Plungerpumpe ass. Pompe à piston plongeur ass. Plunjerpomp ass.
Fußtritt (Pedal) pédale à pied
Freigabepedal pédale à débloquer
Griff Ass. Tige ass.
Verschlußschraube Vis de fermeture ass.
Ass.
Schraube vis
Knopf ass. Boulon ass.
Sattel Zubehör semelle platine acc.
Sattel Ass. Semelle ass.
Rad Ass
Luftmotor Ass. moteur d'air ass.
PU Rohr Ass. PU tuyau ass.
Lufteinlaßventil Ass. soupape entrée d'air ass.
Aufkleber Étiquette
Anleitung Notice Explicative
Reparatursatz jeu de réparation
5645456455Jl;k
Description
oué ass.
Omschrijving Qty. Part No.
1
1
pedaal 1
1
deblokkeerpedaal 1
1
Handle ass. 1
1
Afsluitplug ass. 1
1
schroef 1
1
Knop ass. 1
1
Schotel acc. 1
1
Schotel ass.
1
1
Wiel ass. 1
1
luchtmotor ass. 1
1
PU pijp ass. 1
1
luchtinlaatklep 1
ass. 1
1
Label
1
Handleiding 1
1
1
reparatieset
1
41000-01
41001-01
41000-02
41001-02
41000-03
41001-03
41000-04
41001-04
41000-05
41001-05
41000-06
41001-06
41000-07
41001-07
41000-08
41001-08
41000-09
41001-09
41000-10
41001-10
N/A
41001-11
N/A
41001-12
N/A
41001-13
41000-14
41001-14
41000-15
41001-15
41000-16
41001-16
