GETTING TO KNOW YOUR COFFEE MACHINE
1. On/Off general button
2. Equipment body
3. Control panel
4. Water tank
5. Water tank cover
6. Capsule housing
7. Capsule housing opening lever
8. Used capsule container
9. Cup tray
10. Drip basin
11. Extraction nozzle
12. Electrical plug*
13. Electrical cable
* Except in the UK
CONTROL PANEL
A. Espresso extraction button/water button
B. Long coffee extraction button/water button
C. Long drinks extraction button/water button/purge
A.
7
6
3
8
11
9
10
B. C.
QOOL
5
1
4
12
2
13
